SKU: 9PX8KIRTNBP31

Eaton (9PX8KIRTNBP31) 9PX 8kVA Online 3:1 UPS - Netpack

SKU: 9PX8KIRTNBP31

kVA: 2.2kVA

Watts: 2200

  • Runtime at 70% load: UPS only 10m / 1 EBM 25m / 2 EBMs 42m / 3 EBMs 59m / 4 EBMs 81m / 5 EBMs 97m / 6 EBMs 119m / 7 EBMs 136m / 8 EBMs 154m / 9 EBMs 169m / 10 EBMs 183m / 11 EBMs 196m
  • Online double-conversion technology to constantly monitor power conditions & regulate voltage & frequency
  • Internal bypass allows service continuity in case of internal fault
  • 0.9 power factor delivers 28% more power than other UPSs in its class
  • Versatile 6U rack/tower format (includes rack-mounting kit)
  • Innovative graphical LCD display brings all operating information at first sight
  • Load segment control enables prioritised shutdowns of non-essential equipment during outages
  • Parallel operation using HotSync technology
  • Eaton ABM battery management technology
  • Hot-swappable internal batteries
  • External hot-swappable battery modules can be added for longer power availability
  • Maintenance Bypass
  • (1) USB port, (1) RS232 serial port (USB & RS232 ports cannot be used simultaneously), (4) dry contacts (DB9), (1) mini terminal block for remote On/Off & (1) for remote power Off, (1) DB15 for parallel operation
  • (1) slot for Network-M2 (included), Network-MS, ModBus-MS or Relay-MS management cards
  • Input: Terminal block (three-phase)
  • Output: Terminal block + (4) IEC C19 (16 A)
  • 2-year warranty on electronics & batteries

Call Us: 0800 080 3118 REQUEST FURTHER DETAILS

The Eaton 9PX UPS series delivers energy-efficient power protection for small-to-medium-sized data centres, IT rooms, and critical infrastructure. IT and facilities managers who are worried about energy costs and looking for next-generation power protection solutions will find the 9PX to be a great choice. It offers online double-conversion protection while using 40% less energy, making it a great choice for both groups.

Using HotSync technology, the 9PX (5-11kVA) may be paralleled to generate twice the power of a unitary product at no additional expense.

Energy Star certified, the Eaton 9PX offers the best level of energy and cooling expense savings. 9PX can measure energy consumption down to the outlet group level. Monitor kWh numbers using the LCD or Eaton's Intelligent Power Software.

With an optional network card and Eaton's Intelligent Power Software Suite, which works with all major operating systems, the 9PX works well with leading virtualization environments and cloud orchestration platforms.

Manufacturer: Eaton
Color: Black
Topology: Online Double-Conversion
VA: 2200
Watt: 2200
C19: 4
Output Voltage: 200/208/220/230/240V
Input Frequency: 40-70Hz
Output Frequency: 40-70 Hz + 50/60 Hz autoselection + frequency converter as standard
Communications Ports: 1 USB port + 1 RS232 serial port (cannot be used simultaneously) + 4 dry contacts (DB9) + 1 mini terminal block for remote On/Off and 1 for remote power Off + 1 DB15 for parallel
Operating Temperature: 0 to 40°C
Certification: IEC/EN 62040-1, UL 1778, IEC/EN 62040-2, CE, CB, CSA 22.2, CISPR22 Class B, FCC Class A, IEC/EN 62040-3 (Performance)
